Cost Effective 60mm Plain Bearing Block
Selden's 60mm Plain bearing range is one of the world's best selling block ranges for very good reason, chosen by yacht manufacturers as OEM equipment, Selden's renowned quality at affordable prices is a winning combination.
From single blocks to doubles with twin cams the 60mm PBB range has a solution for most applications on board. Supplied with 6mm Shackle and integral switch, the block can be used in a static position or allow free rotation.
Plain bearing blocks are typically used for heavy and static loads on board. If performance trimming is a requirement we would recommend Selden's Ball Bearing Block (BBB) range or for extreme loads, Roller Bearing Block (RBB) range.
As a guide the 60mm would typically be found on yachts from 30ft to 40ft using 12mm-14mm ropes.
For smaller diameter 10mm-12mm ropes see Seldens 50mm Plain Bearing Range
Uses
- Halyard & Mast Foot Blocks
- Vangs
- Backstays
- Mainsheet Systems
- Spinnaker Sheets & Guys
- Reefing
- General Purpose Tackles
- Preventers
Construction
- Integral Stainless Steel Strap for high strength & longevity
- 60mm Acetal Sheave
- Glass fibre reinforced composite body and cheeks
Specification
| Description | Part No | Safe Working Load (kg) | Breaking Load (kg) | Weight (g) | Max Line Size | Shackle/Fastner (Ø mm) |
|---|---|---|---|---|---|---|
| Single | 406-001-01R | 1,100 | 2,200 | 200 | 14mm | 6 |
| Single Becket | 406-001-02R | 1,100 | 2,200 | 220 | 14mm | 6 |
| Single Cam | 406-001-03R | 120 | 240 | 310 | 12mm | 6 |
| Single Becket Cam | 406-001-04R | 240 | 4,800 | 330 | 12mm | 6 |
| Double | 406-001-05R | 1,100 | 2,200 | 360 | 14mm | 6 |
| Double Becket | 406-001-06R | 1,100 | 2,200 | 320 | 14mm | 6 |
| Triple | 406-001-07R | 1,100 | 2,200 | 510 | 14mm | 6 |
| Triple Becket | 406-001-08R | 1,100 | 2,200 | 470 | 14mm | 6 |
| Triple Cam | 406-001-09R | 600 | 1,200 | 630 | 12mm | 6 |
| Triple Becket Cam | 406-001-10R | 720 | 1,440 | 650 | 12mm | 6 |
| Fiddle | 406-001-11R | 1,100 | 2,200 | 270 | 14mm | 6 |
| Fiddle Becket | 406-001-12R | 1,100 | 2,200 | 290 | 14mm | 6 |
| Fiddle Cam | 406-001-13R | 360 | 720 | 380 | 12mm | 6 |
| Fiddle Becket Cam | 406-001-14R | 480 | 960 | 390 | 12mm | 6 |
| Fiddle TWIN Cam | 406-001-40R | 120 | 240 | 150 | 12mm | 6 |
| Cheek Block - Flat | 406-001-15R | 1,100 | 2,200 | 150 | 14mm | 3xM6(not included) |
| Cheek Block - R345 | 406-001-16R | 1,100 | 2,200 | 150 | 14mm | 3xM6(not included) |
| Cheek Block - R48 | 406-001-17R | 1,100 | 2,200 | 190 | 14mm | 3xM6(not included) |
| Cheek with Quick Lock, Anti CL | 406-001-18R | 1,100 | 2,200 | 390 | 14mm | 3xM6(not included) |
| Double Cheek with Quick Lock, Anti CL | 406-001-19R | 1,000 | 2,000 | 290 | 14mm | 3xM6(not included) |
| Double Cheek Block | 406-001-20R | 1,000 | 2,000 | 190 | 14mm | 3xM6(not included) |
| Cheek with Quick Lock, CL | 406-001-21R | 1,000 | 2,000 | 390 | 14mm | 3xM6(not included) |
| Double Cheek with Quick Lock, CL | 406-001-22R | 1,000 | 2,000 | 570 | 14mm | 3xM6(not included) |
